| SERIES | CAP-BAB | CAP/2-BAB | ||
|
TYPE |
CAP1610-BAB | CAP1810-BAB | CAP1610/2-BAB | CAP1810/2-BAB |
|
Laser Power |
50W/60W/90W/100W | |||
|
Laser Type |
CO2 sealed laser tube,water-cooled,10.6 um | |||
|
Work Size(mm) |
1600 × 1000 | 1800 × 1000 | 800 × 1000 × 2 | 900 × 1000 × 2 |
|
Cutting Speed |
25-40000mm/min | |||
|
Laser Energy Control |
real-timeadjustable | |||
|
Feeding way |
Automatic feed | |||
|
Feeding System |
Simple feeding device, Automatic correction feeding device (optional) | |||
|
Camera system |
18 million pixel HD SLR camera | |||
|
CCD field of view |
1600X1000 | 1800X1000 | 1600X1000 | 1800X1000 |
|
CCD detection accuracy |
0.5-2mm According to the shooting range adjustment | |||
|
Graphics Format Support |
DST,PLT,BMP,DXF,AI | |||
| Software Support | TAJIMA,CORELDRAW,PHOTOSHOP,ILLUSTRATOR,AUTOCAD(all type of AUTOCAD software in cloth) | |||
|
Dichroic Cutting |
reaches 256 colors to cut | |||
|
Dimensions（mm） |
2400 × 1700 × 2600 | 2600 × 1700 × 2600 | 2400 × 1700 × 2600 | 2600 × 1700 × 2600 |
|
Total power |
1500-1700W | 2000-2200W | ||
◆Large format: maximum one-time processing 1800X1000mm graphics, to overturn the traditional camera cutting machine can process small graphical problems
◆High precision: can cope with complex graphics to achieve high-precision cutting, deformation matching algorithm, the deformation can be precisely cut format
◆Saving materials and environmental protection: multi-model cut and arranged parallel algorithms to improve efficiency, save material, automatic suction humidity and significantly improving the working environment
◆Suitable materials for a wide range: in addition to ordinary processed fabrics, but also joined the deformation matching algorithms to effectively solve the problem of high elastic cloth material cut after deformation
◆Configuration 1800W pixel digital camera, to achieve full-page second shot function,hundreds of samples, shoot second, one second match of advanced vision lighting system, effective guarantee uniformity of brightness of the visual field
Application Of Industry：
Trademarks, Mark weaving, embroidery, toys, gifts, clothing, luggage, leather goods, shoes, textiles, curtains etc.
Applicable Materials：
Cotton, hemp, chemical fiber and other textile and apparel fabrics and leather, wood, acrylic,cardboard and other non-metallic materials.
